MT01Q370I5

Downloads

HCL


Processor, Chipset and Memory


Processor:

  • Intel® i5-9500 – 9th Generation, 6 Cores / 6 Threads (9Mb SmartCache) 3.0 – 4.4 GHz, 64 bits. TDP 65W
  • Intel® VPRO

Chipset: Intel® Q370 – Intel® VPRO
RAM Memory: 1x 8GB DDR4 2666 MHz, Non-ECC, Un-buffered
RAM Supported Memory: Up to 64 GB DDR4 2666 MHz
RAM slots: 4x DIMM (3x free)


Storage


Storage: 1x M.2 2280 SSD 256 GB PCIe NVME
Internal units (Tool-less):

  • 1x internal M.2 2230/2242/2260/2280 SATA / PCIe
  • 1x internal M.2 2230/2242/2260/2280 PCIe
  • 1x internal 2.5”
  • 1x internal 3.5”
  • 1x internal 3.5” / 2.5’’

External units (Tool-less): 2x external 5.25’’, 1x external 3.5’’
Disk Controller: Intel Q370 chipset
SATA Ports: 6x internal SATA 6 Gb/s


System Specifications


Chassis:

  • Desktop Tower. Tool-less.
  • Quick Release Side Panel. Tool-less PCIe Expansion Slots
  • 35.7 x 17 x 39 cm (Height x Width x Depth)

Integrated Graphics Card: Intel® HD Graphics 630 350Mhz – 1.10 Ghz, Simultaneous Triple Display Technology
Expansion Slots:

  • 2x PCI Express 3.0 x16 Slots (1x wired x4)
  • 2x PCI Express 3.0 x1 Slots

Audio: Realtek® ALC892 Audio Codec
Network:

  • 1x Integrated Intel ® I219LM Gigabit Ethernet LAN (10/100/1000 Mb/s)
  • Intel® VPRO
  • PXE – WOL
  • 1x WLAN 802.11a/b/g/n/ac 2×2, 2.4GHz & 5GHz, PCIe (Optional)
  • 1x Bluetooth 4.0 (Optional)

Front and Rear Connectors:

  • 2x DisplayPort 1.2 (by adaptor)

  • 1x HDMI 1.4
  • 1x VGA DSub
  • 1x DVI-D
  • 1x RJ-45 Gigabit Ethernet LAN
  • 3x Rear Audio Jacks, 2x Frontal Audio Jacks
  • 4x Rear USB 3.1 Gen1 Charging & Data (4x Type-A)
  • 2x Rear USB 3.1 Gen2 Charging & Data (1x Type-C, 1x Type-A)
  • 2x Front USB 2.0 Charging & Data (2x Type-A)
  • 2x Front USB 3.1 Charging & Data Gen1 (2x Type-A)
  • 2x PS/2


Supported Technologies

  • Intel® VPRO
  • Intel® Virtualization Technology (Intel® VT-x & VT-d)
  • UEFI BIOS (Updatable)
  • Intel® Turbo Boost 2.0
  • Enhanced Intel® SpeedStep
  • Thermal Monitoring
  • ACPI
  • USB Boot

Power Supply: ATX 350W 80 PLUS® Bronze, PFC
Security: Padlock Loop, Kensington Slot. TPM
Label:

  • Customized according with customer specifications (S/N, MAC, Purchase order, P/N, License, etc)
  • Optional Laser Marking with customer specifications

Manufacturing Services: Customer Master O.S. Cloning – PC and BIOS customization
Warranty:

  • 3 years Off-site – Original Parts – Stock of complete units on-site for replacement
  • Optional 5 years warranty

O.S. Compatibility: Microsoft Windows 10, Linux (RHEL, CentOS, Ubuntu, etc)
O.S. License: Windows 10 Professional OEM stored in BIOS
Others: EPEAT Gold



The design features of the product may vary due to configuration and / or interested implementations upon request.
